3 Axis 4 Axis Vertical Machining Center VMC750 CNC Metal Milling Machine with Auto Tool Change
3 Axis 4 Axis Vertical Machining Center VMC750 CNC Metal Milling Machine with Auto Tool Change
| type | VERTICAL | number of axes | 3 |
| voltage | 380 V, 220 V, optional | table travel (x) (mm) | 700 |
| table travel (y) (mm) | 450 | table travel (z) (mm) | 500 |
| positioning accuracy | 0.01 | repeatability (x/y/z) (mm) | 0.007 |
| spindle taper | BT40 | cnc control system | GSK |
| machining capacity | Medium Duty | no. of spindles | Single, SINGLE |
| machinery test report | Provided | video outgoing-inspection | Provided |
| key selling points | Competitive Price | max. table load(kg) | 600 |
| range of spindle speed | 50 – 8000 | dimension(l*w*h) | 2450*2250*2300mm |
| weight | 3800 | Machine Type | Cnc Vertical Milling Machine |
| Table size | 900*420mm | Max.worktable load | 600kg |
| T slot(number-width-pitch) | 3-18x125mm | Distance from spindle center to guide | 650mm |
| Range of revolution | 50-8000rpm/min | After-sales Service Provided | Online Support |
| Control system | SIEMENS GSK FANUC (optional) | Precision | High Precision Machining Center |
