HMC500 CNC Milling Machine Machining Center for Metal
HMC500 CNC Milling Machine Machining Center for Metal
| type | Horizontal | table travel (x) (mm) | 700 |
| table travel (y) (mm) | 700 | table travel (z) (mm) | 810 |
| repeatability (x/y/z) (mm) | ±0.005 | positioning accuracy | ±0.008 |
| spindle taper | BT40 | no. of spindles | Single |
| tool magazine capacity | 30 | cnc control system | Siemens |
| machining capacity | Heavy Duty | voltage | 220v/380v |
| table size | 500×500 | machinery test report | Provided |
| video outgoing-inspection | Provided | min. time of tool change(s) | 3 |
| key selling points | Competitive Price | weight (t) | 5 |
| max. table load(kg) | 500 | dimension(l*w*h) | 3650*2800*2340mm |
| range of spindle speed | 20 – 3000 r.p.m | rapid feed speed | 1 – 235 |
| After-sales Service Provided | Engineers available to service machinery overseas | Working area | 500*500mm |
| Control system | Siemens System | Spindle | 7.5KW Motor Spindle |
| Machine structure | Cast iron | X, Y, Z Transmission | TBI ball screw |
| Guide rails | HIWIN 35 for X, Y, Z axis | Motor | Siemens servo motor |
| Driver | Siemens servo driver | Name | horizontal milling machine |
