PGC 80NC High Precision Cylindrical Grinder Machine External Grinding Machine Processing 3000mm 4000mm 5000mm 6000mm Workpiece
PGC 80NC High Precision Cylindrical Grinder Machine External Grinding Machine Processing 3000mm 4000mm 5000mm 6000mm Workpiece
| type | Universal | voltage | As client's requirement |
| cnc or not | CNC | core components | Motor, Gear, Engine |
| key selling points | High-Accuracy | machinery test report | Provided |
| video outgoing-inspection | Provided | power (kw) | 22 |
| weight (kg) | 20000 | wheel size(mm) | – |
| dimension(l*w*h) | – | Distance between centers | 3/4/5/6 m |
| Center height | 500 mm | External grinding diameter | 50-800 mm |
| Max. workpiece weight | 3000 kg | External grinding wheel (OD * W * ID) | 900*75*305 mm |
| External grinding spindle speed | 1700 rpm | External grinding wheel peripheral speed | 45 m/s |
| Workhead spindle speed, stepless | 5-50 rpm | Workhead spindle center taper | Metric 80 |
| X/Z axis servo drive motor | 2.2 kw |
