Precision Metal Turning CNC Lathe Machine Ck6180 Horizontal Flat Bed CNC Lathe
Precision Metal Turning CNC Lathe Machine Ck6180 Horizontal Flat Bed CNC Lathe
| type | Horizontal | max. length of workpiece (mm) | 2000 |
| positioning accuracy (mm) | 0.02 | repeatability (x/y/z) (mm) | 0.01 |
| number of axes | 2 | cnc control system | Mitsubishi |
| no. of spindles | Single | tool post stations | 8, 10, 6, 4 |
| machining capacity | Heavy Duty | voltage | Customer's Requirement |
| machinery test report | Provided | video outgoing-inspection | Provided |
| key selling points | High-Accuracy | max. weight of workpiece(kg) | 300 |
| travel (x axis)(mm) | 410 | travel (z axis)(mm) | 3000 |
| width of bed (mm) | 550 mm | dimension(l*w*h) | 4700*1755*1900mm |
| weight | 6000 | CNC or Not | CNC |
| Automatic Grade | Automatic | Name | Large Swing CNC Lathe CK6180 For Big Workpiece |
| Spindle bore | 104mm | Spindle speed | 40-125/110-350/290-950 |
| Control system | SIEMENS GSK FANUC (optional) | Turret Type | 4/6/8 Station Electric Turret |
| Max.swing over bed | 800mm | Color | Customized |
| Power (kW) | 11 |
