Surface Grinder M820 Manual Surface Grinding Machine
Surface Grinder M820 Manual Surface Grinding Machine
| voltage | Customized | cnc or not | Normal |
| machinery test report | Provided | core components | Motor, Bearing |
| key selling points | Easy To Operate | video outgoing-inspection | Provided |
| grinding length(mm) | 530 | table travel (x) (mm) | 530 |
| table travel (y) (mm) | 220 | wheel size(mm) | 200 |
| table size(mm) | 480*200 | weight (kg) | 850 |
| power (kw) | 1.1 | surface roughness(μm) | 0.32 |
| dimension(l*w*h) | 1680*1140*1760mm | Type | Surface Grinding Machine |
| Color | White&Green/Blue | Spindle center to table surface | 440mm |
| Spindle speed | 2850 RPM (50Hz) | T-Slot (number*width) | 1*14mm |
| Grind Wheel Size | 200*20*31.75mm | Table size | 480*200mm |
| Parallelism | 300:0.005mm | Usage | Metal Surface Grinding |
| Certification | ISO BV |
